Technical Specification
| S. No. | Particulars | HPL | TITANIUM | TURBO+ | TURBO | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Total Thickness of the Panel | 6 mm | 4 mm | 4 mm | 3 mm | ||||||||||||||||||
| 2 |
Thickness of the Aluminium Skin (Top skin / bottom skin) |
0.25 mm | 0.50 mm | 0.25 mm | 0.25 mm | ||||||||||||||||||
| 3 | Thickness of LDPE/Mineral Core | 5.5 mm | 3 mm | 3.5 mm | 2.5 mm | ||||||||||||||||||
| 4 | Grade of Aluminium Skin | AA3105 H 24 | AA3105 H 24 | AA3105 H 24 | AA3105 H 24 | ||||||||||||||||||
| 5 | Coating Thickness (Front Coil) | 30µ - 40µ Three Coat Raw Tech Paint System |
30µ - 40µ Three Coat Raw Tech Paint System |
30µ - 40µ Three Coat Raw Tech Paint System |
30µ - 40µ Three Coat Raw Tech Paint System |
||||||||||||||||||
| 6 | Coating Thickness (Back Coil) | 4µ - 7µ Service Coat |
4µ - 7µ Service Coat |
4µ - 7µ Service Coat |
4µ - 7µ Service Coat |
||||||||||||||||||
| 7 | Product Tolerance |
|
|||||||||||||||||||||
| 8 | Coating Thickness | 25-28µ (Two Coat-Two Bake) / 33-35µ (Three Coat-Three Bake) | |||||||||||||||||||||
| 9 | Service Coating Thickness | 5 - 7µ | |||||||||||||||||||||
| 10 | Coil Supplier | Litong Aluminium Industry Co. Ltd. | |||||||||||||||||||||
| 11 | Product Tolerance |
Panel Length ± 4.0 mm, Panel Width ± 2.0 mm Panel Thickness ± 0.2 mm, Coil Thickness ± 0.03 mm |
|||||||||||||||||||||
* Shade may vary from batch to batch. It may be different from one batch to another.
* Please match the batch number before installation. Company liability does not arise if the shades mis-match due to batch variation.
